Thursday, March 7th, 2019
Maptek has released a cold climate model of its award-winning mobile Sentry system for stability monitoring.
The exciting newcomer to the Maptek technology portfolio answers the imperative for continuous, reliable measurements of ground movement no matter the environment.
‘Risk management remains a priority,’ said Product Manager, James Howarth. ‘If anything, the reliable operation of technical equipment is even more critical in extreme conditions.’
‘Climate factors play an important role in the execution of any mining project. Extremely low temperature conditions require considerable planning and logistics, especially from an operator safety perspective.’
Maptek Sentry is a mobile remote monitoring system that uses laser scanning to continuously measure ground movement with extremely fine spatial resolution and accuracy. Housed in a self-contained unit with autonomous power and communications capabilities, Sentry relies on sophisticated software to monitor, analyse and report in real-time.
The Sentry system can operate continuously from -20°C to +50°C, with operation for a limited time in temperatures below -20°C. It requires an XR3 cold climate laser scanner, which has been redesigned and tested to operate at these low temperatures. A removable neoprene jacket for the scanner provides extra protection against wind chill.
Maptek redesigned all of the major components in the standard temperature Sentry mobile system, with significant changes to achieve the required cold climate specifications.
‘Equipment reliability is ultra important in extreme conditions. Sentry is a cost-effective monitoring and survey solution which helps operations manage safety and productivity,’ Howarth added.
In deep cold weather, the charge acceptance of batteries is very low. Keeping batteries warm maximises power output and ability to accept a charge. The battery pack and housing in the Sentry M20 has been redesigned and insulated to keep the unit at a stable operating temperature. Other built-in elements such as generator, hydraulics and electrical systems were adapted to maintain energy efficient, cost-effective operation.
‘What hasn’t changed is the proven capability to monitor multiple areas,’ added Howarth. ‘Customers enthuse on how easy Sentry is to set up and use. Data is displayed intuitively, ready for immediate application in risk management programs.’
The 3D point cloud data that has been collected while monitoring can be used for geotechnical analysis and other applications. The Maptek laser scanner can also be redeployed from the monitoring for routine survey tasks.
‘This flexibility is a major benefit,’ said Howarth. ‘Continuous remote monitoring ensures that despite conditions, mines can keep operating with the confidence that personnel and equipment are safe.’
Sentry systems, including the cold climate capability, are available to order now.
